  • Light road bike disc frame
  • UCI approval frame
  • Full internal routing
  • T47 bottom bracket
  • UDH hanger
  • 32mm tire supported
  • More affordable price
€1.777,95
€1.777,95
Size: Silver Gradient Blue-47cm
Wheelsets: FL38 Max-Shimano 11/12 Speed
Subtotal: €1.777,95
10 customers are viewing this product

Fast Delivery

15-Year Quality Assurance

2-year Warranty

ICAN Flyee road bike disc frame

Flyee & FL Max Disc Wheels

€1.777,95

Flyee & FL Max Disc Wheels

€1.777,95
Size: Silver Gradient Blue-47cm
Wheelsets: FL38 Max-Shimano 11/12 Speed

Introduction

Experience a smoother, faster ride with the Flyee T47 BB road bike disc frame. Its internal routing enhances aerodynamics while its new design offers a lighter weight. With wider rear spacing and UDH hanger, this frame is designed for peak performance. Upgrade your ride with the Flyee.

Specification

Type:  Light weight road bike disc frame

Frame: Flyee (Flat mount)

Material:  Toray T700 & T800 & T1000 carbon

Weave:  Painting

Seat post: 27.2mm round, 0mm offset

Weight: Fork-365+-10g (Painting)

Frame in Glossy Silver Gradient Blue:  52cm-867+-20g

Frame in Glossy W2311:  52cm-890+-20g

Frame in Glossy Dark Red:  52cm-875+-20g

Headtube:  1-1/2",1-1/2"

BB: T47

Available size:  47/ 50/ 52/ 54/ 57cm

Max tire size:  700C x 32mm

Cable plug: Internal Cable Routing

Axle:  100*12mm/142*12mm

Rotor Size: Front-160mm; Rear-140mm

Package included: Frame+fork+seatpost+thru axles+hanger

If you order the handlebar together, the package included will add handlebar and spacers.

Features:

Lightweight and Stiffness

The Flyee frame masterfully balances lightweight design with exceptional stiffness. Utilizing cutting-edge materials and advanced manufacturing techniques, the frame is incredibly light, ensuring swift acceleration and agile climbing. Simultaneously, its optimized stiffness guarantees efficient power transfer, providing riders with a responsive and stable experience. This combination of lightweight and stiffness ensures peak performance for competitive cyclists.

Versatile Tire Clearance

Our Flyee road bike frame offers versatile tire clearance, allowing you to fit a wide range of tire sizes from 25c to 32c. This flexibility ensures optimal performance and comfort on various terrains, providing you with the adaptability to switch between smooth road rides and rougher paths effortlessly.

Internal Cable Routing

Achieving a clean, aerodynamic profile, the internal cable routing not only enhances the bike's aesthetics but also protects cables from the elements, ensuring smoother operation and reduced maintenance.

T47 Bottom Bracket

The T47 bottom bracket offers enhanced durability and superior performance. Its threaded design provides a secure and creak-free fit, while the larger diameter allows for increased stiffness and power transfer. This bottom bracket standard also simplifies maintenance and ensures compatibility with a wide range of cranksets, making it a reliable and efficient choice for serious cyclists.

Universal Derailleur Hanger (UDH) Technology

Our Flyee incorporates the cutting-edge UDH system, which represents a significant advancement in derailleur hanger design. With UDH, finding a compatible hanger becomes straightforward, no matter where your adventures take you. This feature is a game-changer for riders who value reliability and ease of maintenance, especially in remote areas or during long tours.

Custom Painting Service for Personalized Style

Elevate your Flyee road bike with our bespoke painting service, offering unparalleled customization to reflect your unique style and personality. Our service allows you to create a personalized paint job that truly makes your bike stand out. Visit our painting website at icancustompaint.com to bring your dream design to life.

Specification
Type  Carbon Disc Wheelset
Rims  Superlight FL Max Disc Wheels
Material  100% Carbon Fiber Toray T700 & T800
Size  700C
Rim

 Drills: 24/24 Holes
 38mm Depth: Outer Width: 27.3mm   Inner Width: 21mm

52mm Depth: Outer Width: 27.3mm   Inner Width: 21mm

Depth

 38mm

52mm

Profile

 Clincher Tubeless Ready

Hub

 ICAN D28

Centerlock, 12x100/12x142mm

Spoke  Sapim CX-Ray Spokes
Spoke Count  Front: 24   Rear: 24
Spoke Pattern Front: 2-cross
 Rear: 2-cross

Nipple  Alloy  Color: Black
Cassette Compatibility  Shimano 11 speed
Wheelset Weight



FL38 Max: 1300+-20g  Front: 598+-10g  Rear: 702+-10g

 FL52 Max: 1385+-20g  Front: 645+-10g  Rear: 740+-10g

Braking Surface  No Braking Surface
Recommended Tyre Size  700 x 25-32mm
Rider Weight Limit  105kg
Guarantee  2 years
Package Included

A pair of Wheelset

Valves

Rim Tape

Packing Size  81.5cm x 17cm x 65.5cm

Warranty Policy

Every ICAN frame and rim has a useful product life cycle. Each bike, frame and rim will have a unique identification number and warranty card. Complete the provided card and warranty form, and send them to us. Failure to use the provided warranty card will void your warranty. Save your dated receipt for proof of purchase.

Product Group:

Frame and Rim

Applies to all ICAN and Triaero brand bike frame, and FL Max series, AERO Series, and Alpha series rim.

Coverage:

2-year warranty from the date of purchase.

Conditions:

  1. If any manufacturing defect occurs within 30 days of the date of purchase, is obligated to replace the rim(s) and also pay for the shipping cost. If any manufacturing defect occurs after 31 days and up to 2 years, ICAN is obligated to replace the product(s). The product owner is responsible for shipping costs.
  2. If we no longer make the rim you purchased we’ll upgrade you to the newest equivalent model at no extra cost.
  3. The Warranty program is not transferable and only applies to the initial purchaser.

This warranty does not cover:

  • Normal wear and tear (bearings, spokes, nipples, brake tracks, tires, inner tubes, pawls, freehub, seals, rim tape etc.)
  • Products which have been incorrectly installed and/or adjusted.
  • Issues brought about by neglect or poor maintenance.
  • Surface finish and cosmetic treatments (anodizing, decals, etc.)
  • Crash damage.
  • Consequential or incidental damages (where applicable)
  • Products purchased “second-hand”, “used”, “as-is”, or expressly “without warranty”
  • Counterfeit products
  • Unauthorized modification or alteration, including without limitation, any repair performed by anyone other than ICAN or an ICAN-authorized servicer, or outside of the recommendations of ICAN Customer Service

Tips:Please contact the official support of ICAN at the first time when you find a quality problem. Please do not repair our products privately, otherwise we will not bear any warranty.

The following will void your warranty

  • Misuse (Jumping, trick riding, etc.)
  • Modification of wheels
  • Tire pressure exceeding 140psi
  • Improper assembly
  • Installation of parts or accessories not originally intended for, or not compatible with the wheelsets sold.
  • Use of brake pads not designed for carbon wheels

More details can be known from "Warranty & Return".
